Medical Tray Dryer

Get a Price/Quote

MOQ : 1 Unit

Medical Tray Dryer Specification

Heat Source
Electrical / Steam

Power
2 kW 24 kW (Depending on Model)

Fuel Type
Electricity

Power Consumption
As per Model Specification

Temperature
50C to 150C

Usage
Industrial

Material
Stainless Steel

Voltage
220V / 380V / 415V

Size
Different Size

Product Type
Tray Dryer

Technology
Forced Air Circulation

Dimension (L*W*H)
Customizable (standard models available)

Color
Silver

Temperature Control
Digital PID Controller

Door
Double Walled, Insulated

Safety Features
Overload Protection, Overheat Cutoff

Shelves
Removable/Adjustable

Moisture Removal Capacity
High

Application
Pharmaceuticals, Chemicals, Food Processing, Laboratory

Noise Level
Low

Control Panel
Fully Automatic with Safety Interlocks

Finish
Mirror / Matt Finish

Air Circulation
Heavy Duty Blower

Heating Element
High Quality Tubular Heater

Installation
Free Standing / Floor Mounted

Tray Material
SS316 or SS304

No. of Trays
12 / 24 / 48 / 96 trays (as required)

Construction
Double Wall with Insulation

Medical Tray Dryer Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
30 Units Per Month

Delivery Time
7-10 Days

Main Domestic Market
All India

About Medical Tray Dryer

Technical Specification

Model / Size	BMTD-12	BMTD-24	BMTD-48	BMTD-96	BMTD-192
Loading capacity	12 Trays	24 Trays	48 Trays	96 Trays	192 Trays
No. of Doors	1	1	1	2	2
No. of Blowers	1	2	1	2	4
No. of Motors/Hp	1/0.5	1/0.5	1/1.0	2/1.0	4/1.0
Electrical Heating Load for100°C / 200°C / 300°C	3kw / 6kw / 9kw	6kw / 9kw / 12kw	9kw / 15kw / 18kw	15kw / 21kw / 27kw	36kw / 42kw / 48kw
Steam Heater No. of coils	2	2	2	2	2
Steam Pressure	3.3 Kg / Cm2	3.3 Kg / Cm2	3.3 Kg / Cm2	3.3 Kg / Cm2	3.3 Kg / Cm2
Steam consumption	25 LBS / Hr	45 LBS/Hr	60 LBS / Hr	80 LBS / Hr	120 LBS / Hr
Insulation in mm 100°C / 200°C / 300°C	50 / 75 / 75	50 / 75 / 75	50 / 75 / 75	50 / 75 / 75	50 / 75 / 75
No. of Trolleys	Rack System	Rack System	1	2	4
Tray Size (mm)	812 x 406 x 31	812 x 406 x 31	812 x 406 x 31	812 x 406 x 31	812 x 406 x 31
Trolley Dimension(mm)	Fixed Racks	Fixed Racks	840 x 960 x 1780	840 x 960 x 1780	840 x 960 x 1780

Superior Drying Efficiency

The Medical Tray Dryer utilizes forced air circulation and high-quality tubular heaters to ensure uniform moisture removal across all trays. Its customizable configuration allows for tailored solutions depending on process requirements, leading to optimized drying times and high product yield.

Advanced Safety and Control

Equipped with overload protection, overheat cutoff, and a fully automatic control panel featuring safety interlocks, this dryer guarantees operational safety and reliability. The digital PID controller maintains accurate temperature settings, reducing the risk of process errors.

FAQs of Medical Tray Dryer:

Q: How does the Medical Tray Dryer achieve uniform drying across all trays?

A: The dryer employs a heavy-duty blower for forced air circulation, ensuring even distribution of heat and airflow. Combined with high-quality tubular heaters and a digital PID controller, this setup maintains consistent temperatures throughout the chamber, resulting in uniform drying of all trays.

Q: What tray materials are available, and how do they benefit the process?

A: The trays are available in stainless steel grades SS316 or SS304, both offering excellent corrosion resistance and durability. SS316 is suitable for highly sensitive or corrosive materials, while SS304 provides robust performance for standard drying needs. This versatility ensures product integrity during the drying process.

Q: When should I choose a Medical Tray Dryer for my application?

A: You should opt for a Medical Tray Dryer when precise moisture removal, high throughput, and stringent safety are required, particularly in pharmaceutical, chemical, food processing, or laboratory environments. Its adaptable features cater to small batch studies and large-scale production alike.

Q: Where can the Medical Tray Dryer be installed, and what are its mounting options?

A: This dryer is designed for free-standing or floor-mounted installation, making it suitable for factories, laboratories, and production facilities. Its customizable dimensions and multiple tray capacities allow integration into various workspace layouts.

Q: What is the process for operating the tray dryer?

A: Operation involves loading materials onto removable trays, setting the desired temperature via the digital PID controller, and starting the drying cycle. The fully automatic control panel manages heating and airflow, while safety features like overload protection monitor the process. Completed batches are easily retrieved from adjustable shelves.

Q: How does the dryer contribute to operational safety and energy efficiency?

A: Safety is enhanced through overload protection, overheat cutoff, and insulated double walls that minimize heat loss. Efficient moisture removal and low noise operation reduce energy consumption and improve working conditions, contributing to overall process reliability.
